IWAKI Magnetic Pump MXM Series


IWAKI Magnetic Pump MXM Series

  • Price:
  • Conference call
  • Availability:
  • In Stock
  • Brand:
  • Type:
  • Magnetic Pump
  • Series:
  • MXM Series
  • Model:
  • MXM Series
  • Supplier:
  • A&S Pump Co.,Ltd


Contact us

Related Products

The MXM series design offers the best combination of durability, safety and performance for a wide range of chemical process applications. MXM models feature separate impellers and inner magnets maximizing the flexibility and application of the product.


· Dry run capability - With proven dry run capability and our unique self-radiating bearing lubrication circuit (PAT.), the MXM is able to withstand process-upset conditions.

· Heat dispersion holes located strategically behind the impeller facilitate removal of frictional bearing heat and improve bearing lubrication and cooling circuit flow under dry run or poor suction conditions.

· Two piece rear casing design - Offers improved pressure handling capability and a second barrier for improved safety. The front casing features injection-molded liner with guaranteed uniform thickness and is fully covered by a ductile cast iron cover for combination of chemical resistance and mechanical integrity.

· All designs have ANSI 150# flanged connections.

· Dual end supported precision ground shafts and balanced compact high strength

· Samarium Cobalt magnet capsule result in balanced lightweight inner magnet capsule assemblies optimizing torque transmission and pump efficiency.

· High strength rare earth magnets are totally encapsulated within fluororesin moldings.

· Close-coupled back pull-out design - Allows the operator to inspect the pump while leaving the line pressurized
